Page 65
Removal and replacement procedures 65
5.
Install the PCI-X riser board.
a.
Align the riser board on the assembly (1).
b.
Secure the riser board with two screws (2).
6.
Reinstall the PCI riser board assembly.
7.
Perform the post-installation procedure.
Lights-Out 100c remote management card
The HP Lights Out 100c remote management card (IPMI 2.0 compliant) allows users to perform server
management tasks remotely over a LAN or the Internet. It also has a health monitoring function that
tracks and records system events related to the fan status, system temperature, and voltage condition.
The Lights-Out 100c module connector is shown in the figure below.
