Cam style lock and key to secure equipment in combination boxes
Must be ordered separately
Not recommended for weapon storage •
•
C
on
so
les
ANGLED SERIES CONSOLES (AS SERIES)
By: Havis-Shields
C-CB-690-LP3
6" Console Combination Box & (3) 12 volt Lighter Outlets Complete w/EB & FP
Designed to hold control heads that are too deep for AS series console
Includes filler plates (FP) and/or equipment brackets (EB) to completely
enclose mounting area less internal mount options
Design includes a modular (3) lighter outlet box with 15 amp in-line fuse
and wire harness included
16 gauge formed steel housing with extruded aluminum top frame
11.25" long, 9" high, 6" wide
Designed to mount behind AS console to Trak-Mount base or to any flat
surface
No vehicle mounting kit required
See pgs C29-37 for optional console accessories
•
•
•
•
•
•
•
•
6 lbs.
Part Number Weight
6”
11.25”
9”
Optional C-SP-3"
Switch plate shown
C-CB-LOCK
Climate Control Mounting Platform & Radio Relocation Equipment Bracket for
1995-2008 Crown Victoria
Allows permanent computer monitor mounting on Crown Vic dash
without permanent modification of Ford OEM components
Provides a mounting surface for relocating the air conditioner system &
radio controls
Relocates the radio to all the AS Series 25° Consoles (ordered
separately)
Includes wire cover panels (pair) to conceal all wiring
C-WH-RCV 4’ Radio Extension Wire Harness available (see page C76)
•
•
•
•
•
3 lbs.
C-AS-CCP-RAD-CV CLIMATE CONTROL MOUNTING PLATFORM
Accessory box with (3) lighter plug outlets
6" wide x 2-5/8" deep x 5-7/16" high
Lighter outlets include 15 amp in-line fuse and wire harness
Manufactured from 16 gauge formed steel
Designed to mount on console or any flat surface •
•
•
•
4 lbs.
C-AB-LP3 ACCESSORY BOX OPTIONS
Accessory box with (4) switches
6" wide x 2-5/8" deep x 5-7/16" high
On/Off black paddle type rocker switches with red pilot light
Manufactured from 16 gauge formed steel
Designed to mount on console or any flat surface •
•
•
•
4 lbs.
C-AB-SW4
Accessory box with (3) lighter plug outlets and (4) switches
6" wide x 2-5/8" deep x 5-7/16" high
Lighter outlets include 15 amp in-line fuse and wire harness
On/Off black paddle type rocker switches with red pilot light
Manufactured from 16 gauge formed steel
Designed to mount on console or any flat surface •
•
•
•
•
4 lbs.
C-AB-LP3-SW4
