ANGLED SERIES CONSOLES (AS SERIES)
Part Number Weight
Combination Box w/ Hinged Armrest and (3) Lighter Plug Outlets
6" wide, 11.25" long (including lighter outlet box) x 9" deep, 2" thick molded rubber
armrest pad for comfort
The new design includes a modular (3) lighter outlet box with 15 amp in-
line fuse and wire harness included
16 gauge formed steel housing with extruded aluminum top frame
Designed to mount behind AS console to Trak-Mount base or to any flat
surface
No vehicle mounting kit required
Recommended for Trak-Mount mounting
Not recommended for weapon storage
•
•
•
•
•
•
•
7 lbs.
C-CB-1 COMBINATION BOXES
C-CB-2
Combination Box/Removable Hinged Armrest
6" wide, 9" long x 9" high, 2" thick molded rubber armrest pad for comfort
No lighter outlets
16 gauge formed steel housing with extruded aluminum top frame
Designed to mount behind AS console to Trak-Mount base or to any flat
surface
No vehicle mounting kit required
Recommended for Trak-Mount mounting
Not recommended for weapon storage
•
•
•
•
•
•
•
7 lbs.
C-CB-690
6" Console Combination Box Complete w/EB & FP
Designed to hold control heads that are too deep for AS series console
Includes filler plates (FP) and/or equipment brackets (EB) to completely enclose
mounting area less internal mount options
16 gauge formed steel housing with extruded aluminum top frame
9" long, 9" high, 6" wide
Designed to mount behind AS console to Trak-Mount base or to any flat
surface
No vehicle mounting kit required
See pgs C29-37 for optional console accessories
•
•
•
•
•
•
•
6 lbs.
6”
9”
6”
9”
9”
6”
9”
9”
2" thick
molded pad
Optional C-SP-3"
Switch plate shown
C-CB-1-3610-ARM
Combination Box with Removable Hinged Arm Rest, Printer Mount,
and (3) Three Lighter Plug Outlets
6" wide x 9" deep x 13.5" high
Lighter outlets include 15 amp in-line fuse and wire harness
16 gauge formed steel housing with extruded aluminum top frame
Designed to mount behind AS console to Trak-Mount base or any flat
surface
No vehicle mounting kit required
Recommended for Trak-Mount mounting
•
•
•
•
•
•
7 lbs.
9”
