By: Havis-Shields
Part Number
Weight
KEYBOARD AND MONITOR MOUNTS
OTHER COMPUTER SPECIFIC MOUNTS
DATA 911
C-3522-911-3
Data 911 MDS 2000 3rd Generation Monitor Mount
Quick release knob to fold closed for storage
Folding angles from flat to 40° past straight up for a total of 130° travel
Used with Angled Series Consoles & C-TCB bases
Slotted for 85° swivel
Note: The first generation of Data 911 monitor is 10.4" diagonal, black housing, with screen
off center - use Monitor Mount Part # C-3522-911
The second generation of Data 911 monitor is 12.1" diagonal, black housing, with screen
centered in housing - use Monitor Mount Part # C-3522-911
The third generation of Data 911 monitor is 12.1" diagonal, gray housing, with screen
centered in housing
•
•
•
•
5 lbs.
MONITOR MOUNT ASSEMBLY FOR XPLORE TECH iX104 C-3522-XPT
For Model iX104 Tablet PC
Xplore Technologies Monitor Mount
Quick-Release knob to fold closed for storage
Folding angles from flat to 40° past straight up for a total of 140° travel
Used with Angled Series (AS) Consoles and C-TCB bases
Slotted for 85° swivel •
•
•
•
•
3 lbs.
C-KBM-TG3
3 lbs.
Fits Motorola MW-520, Data 911 & Litton (L3) Keyboard all of which use either the (TIPP) Texas
Industrial Peripheral or TG3 keyboard
Adjustable to accomodate keyboards that fall within the following measurements:
Minimum Size Keyboard: 10" wide x 6.25" front to back x 1" high
Maximum Size Keyboard: 14.5" wide x 8.5" front to back x 1.5" high
Mounts to end of most manufacturers consoles w/plate or adjustable TCB telescoping computer base
Spring loaded release designed for one-handed removal
Use with swivel adapter bracket C-3085-UN-1 (page C69) or tilt swivel C-3075-3 (page C60)
•
•
•
•
•
•
•
3 lbs.
C-3329-UNV
C-3522-911-15
Data 911 MDS 2000 3rd Generation Monitor Mount
Fits 15" monitor
Quick release knob to fold closed for storage
Folding angles from flat to 40° past straight up for a total of 130° of travel
Used with Angled Series Consoles and C-TCB Bases
Slotted for 85° swivel •
•
•
•
•
MONITOR MOUNT FOR DATALUX TRACER &TX200 MONITOR C-3522-DLX
Monitor mount for Datalux Tracer & Datalux TX200 monitor
Quick release latch to remove Monitor / CPU ( Tracer Only )
Fold down release knob for dash control access.
Folding angle from flat to 40° past straight up for a total of 130° travel
Used with (AS) Angled Series, (SM) Stout Mount Series consoles & C-TCB bases
Slotted for 85° swivel ability
Includes hardware to adapt Tracer keyboard to C-3065-3 tilt swivel (order C-3065-3 separately) •
•
•
•
•
•
•
5 lbs.
5 lbs.
C68
Contact us at:
Ph: 800.524.9900 or 215.957.0720 Fax: 215.957.0729
E-mail: [email protected] Web: www.havis.com
C-KBM-TG3
Keyboard mounting plate for TG3 SL-86-911
