Heat & Glo • Escape-36DV • 2012-900 • Rev. AB • 10/08 56
C. Service Parts List ESCAPE-36DV
IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts
for your appliance please provide model number and serial number. All parts listed in this
manual may be ordered from an authorized dealer.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
Log Set Assembly LOGS-ESCAPE Y
1 Log 1 SRV750-706
2 Log 2 SRV569-705
3 Log 3 SRV2012-161
4 Log 4 SRV2012-162
5 Log 5 SRV2012-163
6 Log 6 SRV2012-164
7 Log 7 SRV2012-165
8 Log 8 SRV2012-166
9 Panel Metal 2012-185
10
Burner NG
Pre 002868727 SRV2012-013-NG Y
Post 002868727 2012-013 Y
Burner LP
Pre 002868727 SRV2012-013-LP Y
Post 002868727 2012-013 Y
11 Log Grate 2012-002
12 Glass Door Assembly GLA-ESCAPE Y
13 Mesh Assembly MESH-ESCAPE Y
14 Orange Kapton Lens 2012-114
15 Light Socket Assembly 2012-010
75 Halogen Bulb mini-can base 700-540 Y
Fiber Patch Kit SRV-PACK
Flue Restrictor ( 3” Diameter) 2012-124
Glass Latch 386-122A Y
Junction Box 4021-013 Y
Mesh Rod 2012-158
Mineral Wool 050-721
Multi-functional Wall Switch WSK-MLT
Mystic Embers MYSTIC-EMBERSXL
Non-Combustible Assembly 2012-036
Refractory Panels (Sold as set only)
Pre 002768335 FRONT-PANEL-KIT
Post 002768335 E36-PANEL-KIT
Conversion Kit NG NGK-ESCAPE-36DV Y
Conversion Kit LP LPK-ESCAPE-36DV Y
Pilot Orifi ce NG
Pre 002868727 446-505 Y
Post 002868727 593-528 Y
Pilot Orifi ce LP
Pre 002868727 446-517 Y
Post 002868727 593-527 Y
Regulator NG NGK-DXV Y
Regulator LP LPK-DXV Y
Additional service part numbers appear on following page.
