Heat & Glo • Escape-36DV • 2012-900 • Rev. AB • 10/08 17
Figure 5.9
Two Elbows
H
1
V
1
V
2
V
1
+ V
2
Minimum H Maximum
1-1/2 ft. 457 mm 2 ft. 610 mm
2 ft. 610 mm 2-1/2 ft. 762 mm
2-1/2 ft. 762 mm 5-1/2 ft. 1676 mm
3-1/2 ft. 1067 mm 8-1/2 ft. 2591 mm
4-1/2 ft. 1372 mm 11-1/2 ft. 3505 mm
V
1
+ H
1
+ V
2
= 63 ft. (19.2 m) Maximum
H
1
+ H
2
= 23 ft. (7.1 m) Maximum
Note: Must have a 12 inches
minimum vertical vent before
attaching any elbow to the unit.
