LEDs, buttons, and switches
69
HP BladeSystem p-Class 3U Power Enclosure LEDs
The power enclosure has two LEDs, one for each bus, to indicate DC power
presence. Use the following figure and table to identify LED locations and
functions.
Item
LED Description
Status
1
Bus B DC power
Off = No DC power available
Green = DC power available
2
Bus A DC power
Off = No DC power available
Green = DC power available
