Cabling and powering up the system 53
•
Scalable bus bar configuration example (on page 53 )
•
Two mini bus bar configuration example (on page 54 )
•
Redundant mini bus bar configuration example (on page 55 )
•
Full rack 42U solution with two pairs of mini bus bars (on page 56 )
•
Configuring the Dynamic Power Saver (on page 57 )
Scalable bus bar configuration example
CAUTION: Always use blanking panels to fill empty vertical
spaces in the rack. This arrangement ensures proper airflow. Using a
rack without blanking panels results in improper cooling that can lead to
thermal damage.
