52 HP BladeSystem p-Class Enclosure Installation Guide
WARNING: If using facility DC power, cables must be
connected by a licensed electrician or trained service personnel
familiar with high-power circuitry.
To connect the grounding cable:
1. Insert the mounting screw through the grounding cable lead and into the
enclosure (1).
2. Tighten the mounting screw to secure the grounding cable to the enclosure
(2).
3. Repeat steps 1 and 2 as needed for the configuration until all enclosures in
the rack are connected by the grounding cable.
4. Connect the lower end of the grounding cable to the facility grounding
connection.
Installing the cable bracket
Install the cable bracket (optional) provided with each power distribution kit.
Configuration examples
Refer to the following examples for typical HP BladeSystem configurations:
