Server operations 27
Removing PCI riser board assembly
CAUTION: To prevent damage to the server or expansion
boards, power down the server and remove all AC power cords before
removing or installing the PCI riser cage.
NOTE: If the expansion slot is populated with the standard PCI-X
storage controller card, it should not be converted to PCI Express.
1. Power down the server ("Powering down the server" on page 24 ).
2. Extend the server from the rack, if applicable ("Extending the server from the
rack" on page 25 ).
3. Remove the access panel ("Removing the access panel" on page 26 ).
4. Remove the PCI riser board assembly:
a. Disconnect external cables connected to any existing expansion boards.
b. Loosen the four PCI riser board assembly thumbscrews.
c. Lift the front of the assembly slightly and unseat the riser boards from
the PCI riser board connectors.
