82 HP Digital Entertainment Center
One Cable TV Box or Digital Cable Receiver
Connect the TV signal source from the standard cable TV
set-top box or digital cable receiver (sold separately) into
the HP Digital Entertainment Center.
If you are using a standard set-top box or digital cable
receiver with S-video or composite video output, do the
following:
1 Make sure that a coaxial cable connector from your
cable TV source (wall) is plugged into the set-top box
or digital cable receiver In connector.
2 Connect a video cable:
a Choose a video out connector:
■ Coaxial (RF)
■ Video (composite)
■ S-video
b Connect the video cable from the set-top
box or digital cable receiver back panel Video
Output connector.
c Connect the video cable into the HP Digital
Entertainment Center back panel TV Source 1 In
connector.
3 Connect stereo audio cables (skip this step if using
coaxial [RF]):
a From the set-top box or digital cable receiver
back panel Audio Out right (red) and Audio Out
left (white) connectors.
b Into the HP Digital Entertainment Center back
panel TV Source 1 In Audio right (red) and Audio
left (white) connectors.
4 Connect the set-top box Infrared Transmitter cable
(required for signal). See “Infrared Transmitter
Connection” on page 90.
