Connecting the power adapter – HANNspree ST43-15A1 User Manual
Page 28
27
Connecting the Power Adapter
1
Connect the power cord to the power adapter as illustrated.
2
Plug the power adapter connector into the DC-IN on the rear panel of
the TV.
3
Plug the three-pronged plug at the other end of the power cord into a
power outlet.
AV1
LINE OUT
ANT
DC-IN
VIDEO
L
R
S-VIDEO
AV2
Power cord
DC-IN
Power outlet
Power adapter
Three-pronged
plug
