Input and Output Ports
Description
Function
1
AV2
Use the included 4-in-1 Audio/Video
cable to connect external devices, such
as a VCR, VCD, or DVD player.
Audio Input: AV connectors white and
red audio cables.
Video Input: AV connector video (yel-
low) or S-Video cables.
2
Line out
Connects to external amplifier.
AV1
LINE OUT
ANT
DC-IN
VIDEO
L
R
S-VIDEO
AV2
1
2
3
4
5
Connect the stand
to the LCD TV as
shown above.
