page 124 008-0608-00
13.2 Wiring
The pin-out for the Relay Output channel’s 12-pin connector is shown in the following
table.
Table 2-8: Relay Output Channel Pin Connections
Pin Label Function Reference Pin
1 (top) RELAY1 NC Relay 1 normally closed 2
2 RELAY1 C Relay 1 common -
3 RELAY1 NO Relay 1 normally open 2
4 RELAY2 NC Relay 2 normally closed 5
5 RELAY2 C Relay 2 common -
6 RELAY2 NO Relay 2 normally open 5
7 RELAY3 NC Relay 3 normally closed 8
8 RELAY3 C Relay 3 common -
9 RELAY3 NO Relay 3 normally open 8
10 RELAY4 NC Relay 4 normally closed 11
11 RELAY4 C Relay 4 common -
12 (bottom) RELAY4 NO Relay 4 normally open 11
