Rev 3.01
25
Document 900.0399
08/08
4
Front Panel Operation
This chapter explains:
•
Live viewing
•
Searching
•
Playing back
•
Live networked remote monitoring
•
Archiving video to a USB memory stick
Note
This chapter assumes you have already correctly installed and configured
your DVR. If you have not, see
for Installation and
for
Configuration.
Live Viewing Window
In the Live window, video inputs from the cameras are displayed as they are configured in
the Live Setup screen (see
).
shows the layout of the live
viewing window. Various on-screen display (OSD) symbols, which indicate the status of the
DVR, are described in
.
Figure 4-1
Live Viewing Window
