Internal power cabling, Scsi model cabling – HP DL385 User Manual
Page 68
Server cabling 68
Internal power cabling
Item Description
1
System power cable
2
Power supply signal cable
3
SAS power cable
SCSI model cabling
IMPORTANT: If a simplex or duplex cabling configuration is not cabled correctly, the SCSI configuration
error LED will illuminate. Refer to "SCSI Backplane LEDs (on page
)" to locate the LED.
NOTE: The server ships with two identical short SCSI cables. Two optional long SCSI cables may be
obtained for PCI Array Controllers. One optional terminator board may be obtained to support duplex SCSI
configurations.
