Page 67

2-34
Removal and Replacement
Service Manual
NOTE: This section applies only to HP Pavilion ze5x00, HP nx9010 and HP nx9008, and
Compaq Presario 2500 models.
Required Equipment
• 1 Phillips screwdriver
Removal Procedure
1.
Unplug the AC adapter, if present, and then remove the battery.
2.
Remove these additional assemblies:
•
•
•
•
•
Display assembly (page 2-23)
•
3.
Remove the insulating tape that secures the floppy drive flex cable to the TouchPad bracket on
the top case.
4.
Remove the four M2.5×6.0mm screws that secure the floppy drive and floppy drive bezel to
the top case.
5.
Remove the floppy drive.
6.
Remove the M2.0×3.0mm screw that secures the floppy drive bezel to the floppy drive.
7.
Remove the floppy drive bezel.
