Cursor Info Box Track 1
Latitude and Longitude Position of Cursor 2
Distance to Cursor 3
Bearing to Cursor 4
Depth 5
10
Boat Icon 11
Waypoint 12
Course Projection Line 13
Active Cursor 14
Declutter icons 15 Temp: Water Surface Temperature 6
Speed: Speed of Boat 7
Course: the current direction the boat is traveling measured in degrees from North 8
VLT: Voltage 9
Cartography 16
Map Scale 17
Chart View (with Cursor) with optional-purchase Navionics® Cartography
1
2
3 4
5 6 7 8 9
10
12
14
17
11
13
15
16
