QuickSpecs
HP Workstation xw8000
DA-11506
North America — Version 11 — June 2, 2003
44
Technical Specifications
ATI FIRE GL 8800 Graphics Card Form Factor
ATX
Graphics Controller
ATI Radeon 8800 GPU
Bus Type
AGP 1x/2x/4x Version 2.0 compliant
RAMDAC
400MHz/30-bit
Memory
128MB DDR SGRAM unified frame buffer, Z-buffer and Texture storage
Connectors
DB-15 analog and DVI-I analog/digital monitor outputs
Dimensions
Single short form factor AGP/ATX card. 174.63mm x 107.96mm
Multi-monitor support
Dual Screen output for resolutions up to 2x1600x1200x32 bit
128 MB DDR SGRAM unified frame buffer, Z-buffer and Texture storage
64 KB BIOS Serial Flash ROM, reprogrammable by SW, 3.3V only, no Jumpers
2D and 3D acceleration provided for 16-bit and 32-bit RGB modes
Hardware cursor with full color alpha channel (64x64x32bpp)
24-bit Z, 8-bit stored alpha and 8-bit Stencil planes
Bus mastering support for 2D/3D display lists and local memory vertex list
execution
Hardware lighting support for up to 8 lights
Cubic Environment Mapping and 3D Texture support
Full Scene Anti-Aliasing (FSAA) support with multisampling up to 6x
Video Engine supports YCrCb (4:2:2, 4:1:0, 4:2:0) conversion
Video scaling and up to 8x4 tap filtering supported for all YUV and RGB16/32
formats
Dual Screen output for resolutions up to 2x1600x1200x32 bit
Per window double buffering on all screen resolutions
Compliant with Microsoft/Intel PC2001 Workstation requirements
Video Timings compliant with VESA DMT 1.0 and VESA GTF 1.0 specifications
DDC2B+ Monitor support on all OS platforms
Additional product features
ACPI Version 1.0b Power Management support (all modes)
Sideband Addressing
AGP Texturing (Execute Mode)
AGP1x/2x/4x Version 2.0
compliant including
Fast writes support
275 MHz engine clock rate
VGA controller
2D Engine with 128-bit datapath processing multiple pixels per clock
PIXEL TAPESTRY II, 3D rendering engine utilizing 4 parallel pipelines each
capable of handling up to 6 textures in a single pass, delivering 2.4 Gigatexels/s
fill rate
CHARISMA ENGINE II, geometry engine delivering up to 75 million transformed,
clipped and lit triangles per second peak processing capability
VIDEO IMMERSION II, industry leading video technology
Dual independent display controllers
Radeon 8800 GPU featuring:
128-bit external frame buffer interface running at a clock rate of 300 MHz DDR
provides a memory bandwidth of up to 9.6 GB per second
Supported graphics APIs
OpenGL 1.3 ICD with immediate mode support for all OGL primitive types
DirectX 8.1
Available graphics drivers
HP-tested Windows XP
HP-tested Windows 2000
HP-tested Linux
HP qualified drivers may be preloaded or available from the HP support Web
site:
