QuickSpecs
HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 41
Technical Specifications
Form Factor ATX NVIDIA Quadro2 EX Graphics
Card
Graphics Controller NVIDIA NV11GL GPU
Bus Type AGP 2x/4x Version 2.0 compliant
RAMDAC 350MHz
Memory 32MB SDR SDRAM unified frame buffer, Z-buffer and Texture storage
Connectors DB-15 analog monitor output
Dimensions (LxWxH) Single short form factor AGP Low Profile card.
6.5 x 2.5 x 0.6 in/16.51 x 6.35 x 1.5 cm
Multi-monitor support
32MB SDR SDRAM unified frame buffer, Z-buffer and Texture storage
VESA 3 (flash ROM) BIOS
24-bit Z, 8-bit stored alpha and 8-bit Stencil planes
Compliant with Microsoft/Intel PC2001 Workstation requirements
Video Timings compliant with VESA DMT 1.0 and VESA GTF 1.0 specifications
DDC2B+ Monitor support on all OS platforms Additional product features
ACPI Version 1.0b Power Management support (all modes)
Sideband Addressing
AGP Texturing (Execute Mode)
AGP 2X/4X Version 2.0
compliant including
Fast writes support
175 MHz engine clock rate
128-bit external frame buffer interface running at a clock rate of 166 MHz
VGA controller
2D Engine with 128-bit datapath processing multiple pixels per clock
Integrated transform and lighting engines
NVIDIA Shading Rasterizer enabling real-time per-pixel effects
Cube environment mapping
Microsoft DirectX and SCTC Texture compression
High performance 2D rendering engine
NVIDIA NV11GL GPU
featuring:
High-Definition Video Processor for full-screen, full-frame DVD playback
Supported graphics APIs OpenGL 1.2 and below
DirectX 7 and below
Available graphics drivers HP-tested Windows XP
HP-tested Windows 2000
HP qualified drivers may be preloaded or available from the HP support Web
site: http://www.hp.com/workstations/support
SINGLE CRT DISPLAY
Resolution Maximum Refresh Rate Bits per Pixel
NVIDIA Quadro2 EX Graphics
Card display resolutions &
refresh rates
640x480 240Hz 8, 16, 24/8
800x600 240Hz 8, 16, 24/8
1024x768 200Hz 8, 16, 24/8
1152x864 170Hz 8, 16, 24/8
1280x1024 150Hz 8, 16, 24/8
1600x900 120Hz 8, 16, 24/8
1600x1200 100Hz 8, 16, 24/8
1600x1280 127Hz 8, 16, 24/8
1920x1080 85Hz 8, 16, 24/8
1920x1200 85Hz 8, 16, 24/8
1920x1440 85Hz 8, 16
1920x1440 75Hz 24/8
2048x1536 75Hz 8, 16
2048x1536 60Hz 24/8
