HP xw8000 - Manual (Page 40)

QuickSpecs
HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 40
Technical Specifications
Form Factor ATX
Graphics Controller Integrated Quadro4 2D/3D 128-bit graphics processor unit (GPU)
NVIDIA Quadro NVS 400 Graphics
Card
Bus Type PCI
RAMDAC Dual 350 MHz
Memory 64 MB 220 MHz, 4mx 32 DDR per GPU, 32 MB per GPU unified frame buffer
Connectors Dual LFH-60
Dimensions Low-profile form factor
Multi-monitor support 1 to 4 displays with nView – with two cards (1 PCI per card), up to 8 monitors
can be driven
nView Hardware Architecture 32-bit color
2048x1536 @ 75Hz maximum resolution
Dual 350MHz RAMDACs
Integrated TMDS
Digital Vibrance Control (DVC)
High-performance 2D rendering engine
Optimized for 32-, 24-, 16-, 15- and 8-bpp modes
High-definition video
processor (HDVP)
Full-screen, full-frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT Motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling
Supported graphics APIs Fully compliant with OpenGL 1.3 and DirectX 8.1
Available graphics drivers Microsoft Windows XP and Microsoft Windows 2000, Linux
See: http://www.hp.com/workstations/support
SINGLE CRT DISPLAY
Resolution Maximum Refresh Rate Bits per Pixel
NVIDIA Quadro NVS 400 display
resolutions & refresh rates
640 x 480 120 Hz 8, 16, 24
800 x 600 120 Hz 8, 16, 24
1024 x 768 120 Hz 8, 16, 24
1152 x 864 120 Hz 8, 16, 24
1280 x 1024 120 Hz 8, 16, 24
1600 x 1200 100 Hz 8, 16
1600 x 1200 85 Hz 8, 16, 24
1920 x 1080 100 Hz 8, 16
1920 x 1080 75 Hz 8, 16, 24
1920 x 1200 85 Hz 8, 16
1920 x 1200 70 Hz 8, 16, 24
1920 x 1440 75Hz 8, 16
1920 x 1440 60Hz 8, 16, 24
2048 x 1536 60Hz 8, 16
