QuickSpecs
HP Workstation xw8000
DA-11506 North America — Version 11 — June 2, 2003 27
Technical Specifications
HP 2-button scroll mouse Scroll Wheel 8 mm
Maximum Rotation Speed 30 mm/s
Switch Type Light force micro-switch
Switch Life 1 million operations
Mechanical Life Minimum 200,000 revolutions
Environmental Operating Temperature 50° to 122° F/10° to 50° C
Non-operating Temperature -22° to 140° F/-30° to 60° C
Operating Humidity 10% to 90% (non condensing at ambient)
Non-operating Humidity 20% to 80% (non condensing at ambient)
Operating Shock 40 g, 6 surfaces
Non-operating Shock 80 g, 6 surfaces
Operating Vibration 2 g peak acceleration
Non-operating Vibration 4 g peak acceleration
Electrical Operating Voltage +5VDC ± 10%
Power Consumption 15mA
System Consumption PS/2 mini-din connector
ESD CE level 4, 15 kV air discharge
EMI-RFI Conforms to FCC rules for a Class B computing
device
PC98 Functionally compliant
Mechanical Resolution 400 ± 20% DPI
Tracking Speed 10 in/s maximum
Acceleration 100 in/s
Switch Actuation 85 g nominal peak force
Switch Life 1,000,000 operations (using Hasco modified
tester)
Cable Length 2 m
PC98-99 Mechanically compliant
Regulatory approvals UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BCIQ, C -Tick
Features Six degrees of freedom motion control through the X, Y, Z axis (pitch, roll, yaw) SpaceBall 4000
Certified for leading CAD and DCC applications
Dimensions/Weight Height 3.0 in/7.6 cm
Length 8.4 in/21.3 cm
Width 6.0 in/15.2 cm
Weight 1.4 lb/0.64 kg
Mechanical Force range 0.5 - 8.2N (1.8 – 29.5 oz)
Torque range 6.91 Nmm (0.085 – 0.33 oz-in.)
Resolution 10-bits
Serial Specifications Connector 9-pin D-subminiature receptacle (DB9S)
Cable Length Approx. 3.9m (12.8 ft) captive
Data rate 9600 bps
Flow control Xon/Xoff
Regulatory Approvals Compliant UL, cUL, EN 950, EN 60950, CSA, FCC, CE
Mark, TUV, CISPR 22, EN 50082, IEC 1000 4-2,
IEC 1000-4-3, AS/NZS, VCCI, BSMI, C-Tick
