3-5 Replacing the ADF Window
..
....
...
....
....
...
....
...
....
....
...
....
....
...
....
...
....
....
...
....
....
...
....
....
...
....
...
....
....
...
....
....
...
....
...
..
..
....
...
....
....
...
....
....
...
....
...
....
....
...
....
....
...
....
...
....
....
...
....
....
...
....
...
....
.
To install the ADF window:
1 Position the four Z-shaped hooks of the ADF window
into the four holes on the bottom of the ADF.
2 Rotate the ADF window back until it contacts the
bottom of the ADF.
3 Check that the long, pointed tab is on the inside of the
ADF.
4 Beginning the with Z-shaped hook closest to the long,
pointed tab, push each of the Z-shaped hooks toward
the back of the ADF.
5 Verify that the long, pointed tab is on the inside of
the ADF.
