SpeedStream Router User Guide
5b. If you selected the
PPPoE protocol and
PPPoE / Bridged type:
Step
On this window:
Do this:
5b
Interface Options
Select interface options: firewall, attack detection system, universal plug
and play; RIP; NAT/NAPT.
6
Connection Name
Enter name to use for this connection.
7
VC Wizard
Finish.
5c. If you selected the
PPPoE protocol and
2684B Connection type:
Step
On this window:
Do this:
5c
2684 Bridged
Enter Internet protocol information as provided by your service provider.
6
Interface Options
Select interface options: firewall, attack detection system, universal plug
and play; RIP; NAT/NAPT.
7
Connection Name
Enter name to use for this connection.
8
PPPoE Session Count
Specify the number (1-4) of PPP sessions you want to configure. For each
session, steps 7-11 will repeat.
9
User Information
Enter user name and password (both are optional).
10
PPP Options
Select PPP options for this connection: dial-up mode, auto-connect on
disconnect, idle timeout
11
PPP Static IP
Enter static IP address (optional).
12
Interface Options
Select interface options: firewall, attack detection system, universal plug
and play; RIP; NAT/NAPT.
13
Connection Name
Enter name to use for this connection. If multiple sessions were selected,
repeat steps 7-11 until last session is configured; then go to step 12.
14
VC Wizard
Finish.
5d. If you selected the
PPPoE protocol and
PPPoE Bridge type, and elected to have the virtual
connection also use 2684B Connection:
Note
If you elected not to have the virtual connection also use 2684B Connection, steps 6, 7 and 8 are not relevant,
and those windows will not display.
Step
On this window:
Do this:
5d
PPPoE with Bridge
Specify whether the virtual circuit (VC) should also use a 2684 Bridged
connection.
6
2684 Bridged
Enter Internet Protocol information as provided by your service provider.
7
Interface Options
Select interface options: firewall, attack detection system, universal plug
and play; RIP; NAT/NAPT.
8
Connection Name
Enter name to use for this connection.
9
PPPoE Session Count
Specify the number (1-4) of PPP sessions you want to configure. For each
