4 • Using the ELP Link III Software 80
Connecting to a PC Laptop Computer
The main cable included in your ELP Link III set connects the PS/2
mouse cable (needed to use the remote control as a mouse) and
9-pin serial cable (needed to use the ELP Link III software and the
Effects buttons on the remote control) to the projector.
1. If you connected the PS/2 mouse cable included with the
projector as described on page 25, disconnect it from the laptop
and the projector.
2. Connect the round end of the main cable to the projector’s
Mouse/Com port.
3. Connect the 9-pin end of the PS/2 mouse cable included with
the ELP Link III set to the MOUSE terminal on the square end
of the main cable.
PS/2 mouse cable
main cable
9-pin serial cable
Mouse/Com port
