Using the Software 97
The following table describes the available options for each
function.
Function Options
Line Width Specify the line width, from 1 to 32 points.
Grid Specify whether to have the line “snap” to the corners of a
grid by entering the size of the sides of the box, in pixels
(dots).
Color Choose a color for the line.
Transparent Click this checkbox to make the background text or image
visible through the line.
Ellipse Width Specify the line width, from 1 to 32 points.
Color Choose a color for the line.
Transparent Click this checkbox to make the background text or image
visible through the ellipse.
Fill Click this checkbox to fill the ellipse with color.
Box Width Specify the line width, from 1 to 32 points.
Color Choose a color for the line.
Transparent Click this checkbox to make the background text or image
visible through the box.
Fill Click this checkbox to fill the box with color.
Make oval
shape Click this checkbox to round the corners of the box.
Bar Width Specify the line width, from 1 to 300 points.
Color Choose a color for the bar.
Direction Choose Horizontal or Vertical.
Transparent Click this checkbox to make the background text or image
visible through the bar.
