System and Control Options
57
7.9 Setup System - Setup System Info
The Setup System Info options allow users to:
• Change Password—used for access to system setup functions
• Change Date & Time/Automatic Daylight Saving Time—used to set the AC8’s date and time
and to enable automatic time change for Daylight Saving Time
• Setup Site ID—the AC8’s location to differentiate among sites if more than one AC8 is in use
• Connect Battery—stops the AC8 battery from backing up the panel
• Backup and Upload Configuration File (Service Terminal Interface only)—permits the
user to copy the AC8’s configuration settings and to upload the file to the AC8
• Setup Serv Ph Num—enables alarm notification to the telephone number entered (in addition
to the four pager numbers).
• Restore Defaults—returns the AC8 to its factory settings
• Perform Firmware Update (Service Terminal Interface only)—changes the AC8’s firmware
to newest version
• Initiate Remote Alarm Test (Service Terminal Interface only)—used to test auxiliary
alarm
To change any Setup System Info features:
Log In and Choose Setup System
• From the Main Menu, use the arrows ↑↓ to choose System and
Control, then press Enter ↵ (see 7.1 - Login for help) .
• Enter your password at the Login screen.
• From the System and Control Menu, use the arrows
↑↓ to choose
Setup System, then press Enter ↵ .
Select Setup System
• From the Setup System Menu, shown at right, use the arrows ↑↓ to
choose Setup System Info and press Enter ↵ .
• Use the steps following Figure 11 to access any of the Setup Sys-
tem Info options.
Figure 11 offers a quick look at the Setup System Info screens available via the LCD interface.
Figure 11 Menu overview - Setup System Info menu
Setup System Menu
SETUP INPUTS
SETUP COMMON ALARM
SETUP SENSOR
↑↓
=NEXT
↵
=SELECT
SETUP ZONES
SETUP OUTPUTS
SETUP MODEM&PAGERS
> SETUP SYSTEM INFO
SETUP OPERATION
SETUP I/O MATRIX
Setup System Info
SETUP SYSTEM INFO
CHANGE PASSWORD
CHANGE DATE & TIME
SETUP SITE ID
CONNECT BATTERY
SETUP SERV PH NUM
FACTORY DEFAULTS
Change Password Change Date & Time Setup Site ID
CHANGE PASSWORD
AAAA
See
Section
7.9.1
CHANGE DATE & TIME
DAYLIGHT SVG TIME: Y
18-MAY-05 10:56:30
See
Section
7.9.2
SETUP SITE ID
AAAAAAAAAAAAAAAAAAAA
AAAAAAAAAAAAAAAAAAAA
See
Section
7.9.3
Connect Battery Setup Serv Ph Num Factory Defaults
IS THE BATTERY
CONNECTED? Y See
Section
7.9.4
ENTER PHONE NUMBER
9,,18005551212
See
Section
7.9.6
RESTORE ALL DEFAULTS
ARE YOU SURE? N See
Section
7.9.8
Setup System Info options
