PixelY1 Result

Applies To

Vision Objects: Line

Description

Returns the pixel Y coordinate of the starting point of a Line object.

Usage

VGet Sequence.Object.PixelY1, var

Sequence Name of a sequence or string variable containing a sequence name.

Object

Name of an object or string variable containing an object name. The object must exist in the
specified sequence.

var

Real variable that will contain the value of the result.

Values

Min: 0
Max Video height- 1

Remarks

Every line must have a starting point and ending point. The PixelY1 and PixelY2 results represent the Y
coordinate position starting (Y1) and endpoints (Y2) of the specified Line object. Since Line object
starting and endpoints can be assigned to other vision objects, the (PixelX1, PixelY1) and (PixelX2,
PixelY2) coordinate pairs can actually be pixel coordinate positions which match the PixelX and PixelY
results for other vision objects. (In other words if a Line object's starting point is defined by a Correlation
object, then the (PixelX, PixelY) results from the Correlation object will match the (PixelX1, PixelY1)
results for the Line object.)
