EPN3600
45
exclusive for Preset mode here.
Speed : Select tour speed from 1 ~255. This option is exclusive for Preset
mode.
2.4.2.2.4 Set Pattern
User can click Program button right next to “Set Pattern” to enter Pattern
window (See
Figure 2-25 ) to set a pattern for a camera.
Figure 2-25 Video – Camera –Pattern Window
1. Enter a number (1~4) in “Pattern No” field.
2. Click “Set” button to start recording a pattern. At this time, the live
screen will show “Recording Tour ..90s”. and the Set button will
switch to “Complete” button.
Note: Maximum pattern recording time is 90 seconds. If your record
reaches 90 second, the screen will show “Recording time
over”. Press “Complete” button to exit.
