EPN3600
28
2.4.1 Multi Streaming
Figure 2-10 Video – Multi Streaming
Stream Setting
The system can output 3 video streams simultaneously. For each of them,
user can set compression format, resolution, quality and frame rate
individually. Stream 1 is always enabled for live view.
Check “Enable” box to enable other streams.
Format : Select encode format from H.264, MPEG4 and MJPEG.
Resolution :
NTSC: 4CIF (704*480) / VGA (640*480) / CIF (352*240) / QVGA (320*240) /
QCIF (176*120)
PAL: 4CIF (704*576) / VGA (640*480) / CIF (352*288) / QVGA (320*240) /
QCIF (176*144)
Quality
: there are 8 types of quality, please choose from Highest / Higher /
High / Middle / Normal / Low / Lower / Lowest.
Frame Rate : select from NTSC: 1 / 3 / 5 / 15 / 30 fps, PAL: 1/ 2.5/5/12.5/25
fps
Note: Total frame rate cannot exceed 60 fps.
System performance may be influenced if user enables 4 video streams
simultaneously.
