EPN3600
40
Set Object Size
User can set desired tracking object size by click “Set” button at ○
12 . Figure 2-22
shows the screen of object size setting.
Figure 2-22 Set Object Size: Max/Min frame
User can set sizes of MAX and MIN frames here and the system will
only track object with size between MAX and MIN frames.
a. Click IRIS- button, , to enter select MAX or MIN frame for
modification. The selected frame will flash at this time.
b. Change the object size by using arrow buttons:
: press this button to increase the length of the mask.
: press this button to decrease the length of the mask.
: press these buttons to increase the width of the
mask.
: press these buttons to decrease the width of the
mask.
c. After completing the setting, click IRIS+ button, , to save
and return to previous menu.
Object Frame: user can set frame of tracking object visible or invisible at ○
13 .
Apply and Reset Buttons ○
14
: Click “Apply” button to save changes. User can
