EATON Power Xpert ® Gateway Series 1000 Card User’s Guide S 164201670 Rev 1 71
Chapter 7
Operation and Maintenance
This section explains:
S
Indicator descriptions
S
DIP switch settings
S
Generating log files
S
Firmware upgrade instructions
Front-Panel Indicator Descriptions
The Ethernet port indicator descriptions for the PXGX Series 1000 Card
are listed in Table 11; the stacked indicator descriptions are listed in
Table 12.
Table 11. Ethernet Port Indicators
Indicator Label Illuminated Not Illuminated
Ethernet Port 1 100 Indicates a valid 100 Mb Connection
(Link). Indicates a valid 10 Mb Connection (Link)
as long as the corresponding ACT
indicator is illuminated.
ACT Indicates network activity when the
indicator is on or blinking. Indicates network activity when the
indicator is on or blinking.
Ethernet Port 2 100 Indicates a valid 100 Mb Connection
(Link). Indicates a valid 10 Mb Connection (Link)
as long as the corresponding ACT
indicator is illuminated.
ACT Indicates network activity when the
indicator is on or blinking. Indicates network activity when the
indicator is on or blinking.
