MODBUS REGISTERS
EATON Power Xpert ® Gateway Series 1000 Card User’s Guide S 164201670 Rev 1 62
Table 5. Panel Summary Registers (FC 04) (continued)
Bytes Data Type Register Name
AC V AN 4010 FLOAT 4
AC V BN 4012 FLOAT 4
AC V CN 4014 FLOAT 4
AC V MAX AN 4296 FLOAT 4
AC V MAX BN 4298 FLOAT 4
AC V MAX CN 4300 FLOAT 4
AC I in A 5002 FLOAT 4
AC I in B 5004 FLOAT 4
AC I in C 5006 FLOAT 4
AC I in N 5010 FLOAT 4
AC I MAX A 5164 FLOAT 4
AC I MAX B 5166 FLOAT 4
AC I MAX C 5168 FLOAT 4
AC I MAX N 5170 FLOAT 4
Percent Full Load Current A 5185 FLOAT 4
Percent Full Load Current B 5186 FLOAT 4
Percent Full Load Current C 5188 FLOAT 4
Watts Total 6006 FLOAT 4
Watts Total MAX 6014 FLOAT 4
VA Total 6070 FLOAT 4
VA Total MAX 6078 FLOAT 4
PF Disp Total 6219 FLOAT 4
PF Disp Sys MIN 6268 FLOAT 4
PF Disp Sys MAX 6288 FLOAT 4
Watts Total MIN 6356 FLOAT 4
VA MIN 6364 FLOAT 4
kW Hour 7618 FLOAT 4
Monthly kW Hour 7620 FLOAT 4
Yearly kW Hour 7622 FLOAT 4
Frequency 11000 FLOAT 4
