MODBUS REGISTERS
EATON Power Xpert
®
Gateway Series 1000 Card User’s Guide
S 164201670 Rev 1
64
Breaker Data and Alarms
This section contains:
S
Names of breaker parameters along with the register numbers for
Breaker #1
S
Instructions for calculating the register numbers for other breakers
S
Breaker alarms
Breaker #1 Data Registers (FC 04)
To specify a specific breaker, use a Unit ID for breaker data along with
the register number for the specific breaker.
For example, “Watts in Phase A” is register 1055 for Breaker #1. This
statement is true for any panel. To specify a specific panel for breaker
data, use the panel’s Unit ID in the Modbus program. For Panel #6
(Unit ID 23), the Modbus program would be set as follows:
IP:
Unit ID: 23
Starting Register: 1055
Number of registers: 2
Function code: 04
The Modbus program would return a value of the watts in Phase A for
Breaker #1 in Panel #6 of the PDU/RPP at the specified IP address.
Table 7. Breaker #1 Data Registers (FC 04)
Name
Register
Data Type
Bytes
Display Name
1000
STRING
64
Number of Phases
1032
UINT
2
Breaker Rating
1033
UINT
4
Breaker Warning
1035
UINT
2
Breaker Overload
1036
UINT
2
AC Current Phase A
1037
FLOAT
4
AC Current Phase B
1039
FLOAT
4
AC Current Phase C
1041
FLOAT
4
AC MAX Current Phase A
1043
FLOAT
4
AC MAX Current Phase B
1045
FLOAT
4
