MODBUS REGISTERS
EATON Power Xpert ® Gateway Series 1000 Card User’s Guide S 164201670 Rev 1 68
Environmental Monitoring Probe (FC 03 or 04)
The optional Environmental Monitoring Probe for the PDU/RPP can
measure temperature and humidity. Because the device can be located
outside the PDU/RPP, the reference is to “auxiliary” data. In addition, it
contains two connections for monitoring the condition of auxiliary input
contacts, such as a door switch. See Table 9 for a list of EMP registers.
An exception code is returned if the EMP is not installed.
To read the temperature at the PDU/RPP, set the Modbus program to
Unit ID 254 and coil address 12028:
IP:
Unit ID: 254
Starting Register: 12028
Number of registers: 2
Function Code: 04
Table 9. Environmental Monitor (FC 03 or 04)
Name Register Data Type Bytes
Vendor Name 1001 STRING 64
Model Name 1033 STRING 64
Display Name 1065 STRING 64
Serial Number 1123 STRING 64
Device ID 1099 UINT 4
Auxiliary Input 1 10275 UINT 2
Auxiliary Input 2 10276 UINT 2
Auxiliary Temperature 12028 FLOAT 4
Auxiliary Humidity 12030 FLOAT 4
