User Manual
EN
CONTROL PANEL
CONTROL PANEL
1. Outlet B (33%)
2. On / Off
3. OLED display
4. EL-Skyport antenna
5. Synchronisation plug for 3.5 mm jack
6. Photocell
7. Micro USB socket / Firmware Update
8. Right function button / Power up
9. Test button / Enter menu function
10. Left function button / Power down
11. Modelling lamp button
12. Outlet A (100%)
13. Access menu button / Return function
11
4
12 10 9
6
2
13
1
8
5
3
7
