74
6-3. Output signals (SDI and HDMI)
Image resolution of SDI OUT signal varies depends on the combination of settings below.
MENU
>
SYSTEM SETTINGS
>
SYSTEM MODE
>
FREQUENCY
and
MAIN PIXEL
MENU
>
OUTPUT SETTINGS
>
SDI OUT
>
SIGNAL SEL
and
OUT FORMAT
MENU SETTING
SIGNAL OUT FORMAT
(OUT FORMAT MENU ITEM)
FREQUENCY MAIN PIXEL
SIGNAL SEL
59.94p
50.00p
4096x2160
SDI
1920x1080p *1, 1920x1080i *1
LCD (1080p)
1920x1080p *2
LCD (1080i)
1920x1080i *2
3840x2160
SDI
1920x1080p, 1920x1080i
LCD (1080p)
1920x1080p *2
LCD (1080i)
1920x1080i *2
2048x1080
SDI
1920x1080p *1, 1920x1080i *1
LCD (1080p)
1920x1080p *2
LCD (1080i)
1920x1080i *2
1920x1080
SDI
1920x1080p, 1920x1080i
LCD (1080p)
1920x1080p *2
LCD (1080i)
1920x1080i *2
1280x720
SDI
1280x720p
LCD (1080p)
1920x1080p *2
LCD (1080i)
1920x1080i *2
59.94i
50.00i
1920x1080
SDI
1920x1080i
LCD (1080p)
1920x1080p *2
LCD (1080i)
1920x1080i *2
29.97p
23.98p
4096x2160
SDI
4096x2160p, 1920x1080p *1, 1920x1080PsF
*1
LCD (1080p)
1920x1080 over 59p *2
LCD (1080i)
1920x1080 over 59i *2
3840x2160
SDI
3840x2160p, 1920x1080p, 1920x1080PsF
LCD (1080p)
1920x1080 over 59p *2
LCD (1080i)
1920x1080 over 59i *2
2048x1080
SDI
1920x1080p *1, 1920x1080PsF *1
LCD (1080p)
1920x1080 over 59p *2
LCD (1080i)
1920x1080 over 59i *2
1920x1080
SDI
1920x1080p, 1920x1080PsF
LCD (1080p)
1920x1080 over 59p *2
LCD (1080i)
1920x1080 over 59i *2
*1 Displayed as letterbox format, image quality may slightly be lower than image recorded.
*2 LCD clone mode, focus and EI assist characters can be displayed, image sampling and bit-depth
becomes 4:2:2 8-bit, blank panels (at top, bottom, left, and right) are always displayed.
