4.2.5 TC
The TC port is a 0B 5-pin push-pull socket for timecode input or
output. For different timecode generators, such as Ambient
timecode generator Nano Lockit, or SoundDevice recorder
which has a TC system, the physical spec and definition are the
same.
# Definition
1 NC, unused
2 NC, unused
3 LTC IN
4 GND
5 LTC OUT
