 D-Tap Power Cord: Connect the D-Tap plug to the D-Tap socket of battery/battery plate, and
connect 2-pin push-pull connector to the 2-pin power socket of the camera body;
 XLR Power Cord: Connect the 4-pin standard XLR connector to the XLR socket on the storage
battery (11~26V), and connect the 2-pin push-pull connector to the 2-pin power port on the
camera body;
 100W Power Cord: Its output is a professional 2-pin push-pull connector, which matches the
power sock of Kine Cameras; another port is USB-C with an E-Mark chip, which best matches 65W
PD Power Adapter to power the camera easily.
CAUTION The voltage of power supply recommends as 11V~26V. Using a Power supply higher than 26V
may burn the body.
CAUTION Please heed the direction of the 2-pin DC IN port on the camera body while plugging/
unplugging the power cords. The red dot/notch indicates the direction in which the power
cable is inserted. Please pay attention to the positive and negative poles of the D-Tap port.
NOTICE A V-mount to Anton-Bauer Plate Adapter is required if you use Anton-Bauer (Gold Mount)
broadcast batteries.
NOTICE When two of the four power supplies are available at the same time, the camera automatically
chooses the source with higher voltage, and allows hot-swap of batteries.
NOTICE To save power, use a different power supply for monitors and turn off WIFI.
NOTICE If the voltage detected is too low to continue shooting, the camera will automatically stop
recording to avoid damage to the clip.
