● HP 300 cm DisplayPort cable and USB/power “Y” cable kit for 25.7 cm (10.1-inch), 35.6 cm (14-inch),
and 39.6 cm (15.6-inch) touch monitors
● HP 300 cm DisplayPort cable and USB power cable kit for the 35.6 cm (14-inch) non-touch monitor
● HP 300 cm DisplayPort cable and USB B-A cable kit for 25.7 cm (10.1-inch), 35.6 cm (14-inch), and 39.6
cm (15.6-inch) touch monitors
● HP 45 W power adapter
Rear components
Component Function
(1) USB 2.0 Type-B upstream port (touch monitors only) Connects a USB cable from the computer to the monitor (required for
touch functionality).
(2) DisplayPort Connects the DisplayPort cable from the monitor to the computer.
(3) DC power connector Connects the power cable from the 12 V powered USB port on the
computer or the external power supply to the monitor.
(4) Mini USB port This port is only used by service technicians to update the firmware on
the monitor.
Product features and components 3
