Effect Parameters
56
Parameter
Value
Explanation
[5]
Sync
OFF
,
ON
When this is ON, the effect synchronizes with the tempo of the rhythm.
(P.28)”
[6]
tiNe
1
–
1300
Adjusts the delay time from the direct sound until the pitch-shifted
sound is heard.
[7]
notE
(P.57)”
[8]
Fb
-98
–
98
(%)
Adjusts the proportion of the pitch-shifted sound that is fed back into
the effect. (Negative values invert the phase.)
[9]
Eq.Lo
-15
–
15
(dB)
Amount of low range boost/cut
[10]
Eq.Hi
-15
–
15
(dB)
Amount of high range boost/cut
[11]
bAL
Volume balance between the effect sound and dry (original) sound
0
Effect sound : Dry sound = 0 : 100
100
Effect sound : Dry sound = 100 : 0
[12]
LEU
0
–
127
Output level
You can also press a step button to select the parameter items.
2V PShifter
Step
buttons Parameter
Value
Explanation
[1]
tyPe
Ptc2
Shifts the pitch of the dry sound. You can layer two pitch-shifted sounds
onto the dry sound.
[2]
Sľ
Off
,
On
Turns the effects on/off.
[3]
1.CrS
-24
–
12
(semitones) Amount of pitch shift applied for pitch-shift 1 (in semitones)
[4]
1.Fin
-100
–
100
(cent)
Amount of pitch shift applied for pitch-shift 1 (in units of two cents)
[5]
1.dÆy
These are the settings for the pitch-shift 1 delay and feedback parameters.
Step
buttons
Parameter
Value
Explanation
[1]
Sync
OFF
,
On
When this is
ON, the effect
synchronizes
with the
tempo of the
rhythm.
(P.28)”
[2]
tiNE
1
–
1300
Time from
when the dry
sound is heard
until the pitch-
shifted sound
is heard
[3]
notE
(P.57)”
[4]
Fb
-98
–
98
(%)
Adjusts the
proportion of
the pitch-
shifted sound
