Effect Parameters
49
Step
buttons
Parameter Value Explanation
[1]
tyPe dLy2
The delay sound is heard both at the left and
at the right.
[2]
Sľ Off , On
Turns the effects on/off.
[3]
Sync Off
,
On
When this is ON, the effect synchronizes with
the tempo of the rhythm.
“ 8.2.1. Tempo Settings (P.28)”
[4]
TiNE 1
–
2600 (ms) Adjusts the delay time from the direct sound
until the delay sound is heard. [5]
notE
“ 12.1.18. About note values (P.57)”
[6]
Fb -98
–
98
(%) Adjusts the proportion of the delay sound
that is fed back into the effect. (Negative
values invert the phase.)
[7]
H.dNP 200
,
250
,
315
,
400
,
500
,
630
,
800
,
1000
,
1250
,
1600
,
2000
,
2500
,
3150
,
4000
,
5000
,
6300 , 8000 (Hz), byPS
Center frequency at which the high
frequencies of the delay sound fed back to the
input are cut
(
byPS
: does not cut the frequencies)
[8]
PAn1 L 64
–
r 63
Delay 1 pan
[9]
PAn2 L 64
–
r 63
Delay 2 pan
[10]
LUL1 0
–
127
Delay 1 volume
[11]
LUL2 0
–
127
Delay 2 volume
[12]
EQ.Lo -15
–
15 (dB) Amount of low range boost/cut
[13]
EQ.Hi -15
–
15 (dB) Amount of high range boost/cut
[14]
bAL
Volume balance between the effect sound and dry (original) sound
0
Effect sound : Dry sound = 0 : 100
100
Effect sound : Dry sound = 100 : 0
[15]
LEU 0
–
127
Output level
You can also press a step button to select the parameter items.
Mod Delay
When Feedback Mode is “
norN
” (NORMAL)
