For information on operation modes refer to “Setting the Operation Mode” (p. 25).
Connecting Source Equipment
Connecting SDI equipment
Connect a video camera or other device capable of SDI output to the SDI IN connector.
Connecting HDMI equipment
Connect a video camera or other device capable of HDMI output to the HDMI INPUT connector.
Connecting DVI equipment
Using a conversion cable, connect a computer or other equipment capable of DVI output to the
HDMI/DVI INPUT connector.
