Reference MVI46-103M ♦ SLC Platform
IEC 60870-5-103 Master Communication Module
ProSoft Technology, Inc. Page 177 of 187
September 12, 2006
⌧ <82> Zone 5
⌧ <83> Zone 6
⌧ <84> General start/pick-up
⌧ <85> Breaker failure
⌧ <86> Trip measuring system L
1
⌧ <87> Trip measuring system L
2
⌧ <88> Trip measuring system L
3
⌧ <89> Trip measuring system E
⌧ <90> Trip I>
⌧ <91> Trip I>>
⌧ <92> Trip IN>
⌧ <93> Trip IN>>
7.9.15 Auto-reclosure indications in monitor direction
INF Semantics
⌧ <128> CB 'on' by AR
⌧ <129> CB 'on' by long-time AR
⌧ <130> AR blocked
7.9.16 Measurands in monitor direction
INF Semantics
⌧ <144> Measurand I
⌧ <145> Measurands I, V
⌧ <146> Measurands I, V, P, Q
⌧ <147> Measurands I
N
, V
EN
⌧ <148> Measurands I
L1,2,3
, V
L1,2,3
, P, Q, f
7.9.17 Generic functions in monitor direction
INF Semantics
