MVI46-103M ♦ SLC Platform Reference
IEC 60870-5-103 Master Communication Module
Page 106 of 187 ProSoft Technology, Inc.
September 12, 2006
# Database definition for this session/sector
#
# ASDU Database Function Point
# Type Index Code Index
START
END
[IEC-103 Master Session 7 Sector 2]
Common ASDU Address : 2 #Range 0 to 65534 Sector address
#Req init requests when session first online (not req if slave sends
# EOI sequence)
Online Time sync : Y #Send time sync message when first online
Online General Int : Y #Send general interrogation
#Req init requests when EOI (end of initialization) received from slave
EOI Time sync : Y #Send time sync message when first online
EOI General Int : Y #Send general interrogation
# Database definition for this session/sector
#
# ASDU Database Function Point
# Type Index Code Index
START
END
[IEC-103 Master Session 7 Sector 3]
Common ASDU Address : 3 #Range 0 to 65534 Sector address
#Req init requests when session first online (not req if slave sends
# EOI sequence)
Online Time sync : Y #Send time sync message when first online
Online General Int : Y #Send general interrogation
#Req init requests when EOI (end of initialization) received from slave
EOI Time sync : Y #Send time sync message when first online
EOI General Int : Y #Send general interrogation
# Database definition for this session/sector
#
# ASDU Database Function Point
# Type Index Code Index
START
END
[IEC-103 Master Session 7 Sector 4]
Common ASDU Address : 4 #Range 0 to 65534 Sector address
#Req init requests when session first online (not req if slave sends
# EOI sequence)
Online Time sync : Y #Send time sync message when first online
Online General Int : Y #Send general interrogation
#Req init requests when EOI (end of initialization) received from slave
EOI Time sync : Y #Send time sync message when first online
