16
IMAGE button
Selects image levels.
(P32)
BEFORE OPERATION
MENU
AUTO PC ADJUST IMAGE
SELECT
VOLUME ZOOM FOCUS
LENS SHIFT
ON-OFF
INPUT 1/2
INPUT 3/4
SIDE CONTROLS AND INDICATORS
Adjust zoom. (P23)
INPUT 3/4 button
POWER ON–OFF button FOCUS buttons VOLUME buttons
Select input source either
INPUT 3 or INPUT 4. (P25)
Adjust focus. (P23) Adjust volume. (P24)
Selects an item or adjusts
value in the On-Screen Menu.
(P20)
Executes the item selected.
(P20)
Turns the projector on or
off. (P22)
ZOOM buttons
Select LENS SHIFT function.
(P23)
SELECT button
POINT buttons
LENS SHIFT button
SIDE CONTROLS
MENU button
Open or close the On-Screen
Menu operation. (P20, 21)
INPUT 1/2 button
Select input source either
INPUT 1 or INPUT 2. (P25)
SIDE CONTROLS
REAR
INDICATORS
FRONT
INDICATORS
AUTO PC ADJ. button
Operates the AUTO PC
adjustment function. (P29)
