INPUT 1
INPUT 2
INPUT 3
DVI
AUDIO CONTROL PORT
CONTROL PORT AUDIO
R/Pr G/Y B/Pb H/HV V
(MONO)
(MONO)
R L
R L
(MONO)
AUDIO OUT
R L
R/C JACK USB
SERIAL PORT IN
SERIAL PORT OUT
RESET
INPUT 4
SDI IN1 SDI IN2 SDI OUT
14
CONNECTING PROJECTOR
CONNECTING TO COMPUTER
IBM-compatible computers or Macintosh computers (VGA / SVGA / XGA / SXGA/UXGA)
DVI-VGA Cable
Monitor Output
Desktop type
Laptop type
Audio Cable
(stereo) ✽
Audio Output
Audio Input
AUDIO OUT
MAC/VGA
Adapter
Set slide switches
following chart
below.
Cables used for connection ( ✽ = Cables are not supplied with this projector.)
• DVI Cable
• DVI-VGA Cable (HDB 15 pin)
• MAC/VGA Adapter
• BNC Cable (BNC x 5)
✽
• Audio Cables (RCA x 2) ✽
Audio Cable
(stereo) ✽
NOTE :
When connecting cable, power cords of both a
projector and external equipment should be
disconnected from AC outlet. Turn a projector
and peripheral equipment on before computer is
switched on.
Terminals of
a Projector
Audio Amplifier Audio Speaker
(stereo)
External Audio Equipment
Monitor Output
DVI Cable BNC Cable ✽
Set switches as shown in table below depending on
RESOLUTION MODE that you want to use before
your turn on a projector and computer
13"MODE (640 x 480)
16"MODE (832 x 624)
19"MODE (1024 x768)
21"MODE (1152 x 870)
ON
OFF
OFF OFF OFF OFF
OFF OFF OFF
OFF OFF OFF
ON
ON
ON ON ON
OFF
OFF OFF
ON ON
ON
ON
1 2 3 4 5 6 MODE
SWITCHES
Switches of
MAC/VGA Adapter
ON
1
DIP
ON
OFF
2 3 4 5 6
MAC/VGA ADAPTER
Monitor Output
