4. Setup the GEPON OLT EPL-1000
The followings are instructions for setting up PLANET EPL-1000. Refer to the
illustration and follow the simple steps below to quickly install your GEPON OLT.
Pre-Installation
This section provides the information users have to ware before installing the EPL-
1000. The information includes required installation tools, safety requirements, and
electrostatic discharge protection.
Tools and Test Equipment Requirements
To install and maintain the EPL-1000, you should have the tools and test equipment
listed in the Table 4-1.
Table 4‑1 Required Installation Tools and Materials
Item Required Purpose
Anti-static wrist strap
Protect the EPL-1000 system from electrostatic
discharge damage.
Hand tools
Screw drivers for equipment removal and
replacement.
Wire cutter/stripper Prepare wires for electrical connections.
Accessories and hardware kit
Screws, bolts, etc., for securing the equipment
on the desired location.
Safety Requirement
To prevent possible serious injury, do not apply power to the EPL-1000 system until
you’ve completed all of the installation procedures and connected it to the external
facilities. Be cautious, when turning on/off the EPL-1000 system power.
4.1 Hardware Installation
The PLANET EPL-1000 is a 1U high box-type GEPON OLT with rack-mountable
enclosure. It can be installed in a standard 19-inch rack by using the mounting
brackets provided. Mount the shelf on the rack using the large screws provided.
The procedure to connect and wire the system is as follows.
