2
2 10/100/1000Mbps ports and 2 SFP interfaces (FGSW-2620PVS only)
Auto-MDI/MDI-X detection on each RJ-45 port
Prevents packet loss with back pressure (half-duplex) and 802.3x PAUSE frame flow control
(full-duplex)
High performance Store and Forward architecture, broadcast storm control, runt/CRC filtering
eliminates erroneous packets to optimize the network bandwidth
6K MAC address table, automatic source address learning and ageing
4 Mbit embedded memory for packet buffers
Console and Web interface for Switch basic management and setup
Support up to 26 port-based VLAN groups
Support up to 7 Trunk groups, each trunk for up to maximum 4 port with 800Mbps bandwidth
Port mirroring allows monitoring of the traffic across any port in real time
Support QoS and bandwidth control on each port
Misc Configuration for Switch advanced configuration
" #$ %
Model FGSW-2402PVS / FGSW-2620PVS
Network ports 24 10/100Base-TX RJ-45 MDI/MDI-X ports
Module slot
(FGSW-2402PVS only)
2 open slots for 10/100Base- TX, 1000Base-T and 100Base-FX,
1000Base-SX/LX fiber-optic interface
Gigabit ports
(FGSW-2620PVS only)
2 10/100/1000Mbps ports and 2 SFP interfaces
Console port 1 RS-232 DB-9 male
Dimensions 440 x 200 x 44 mm (1U height)
Weight 2.6 kg
Power Requirement 100~240 (±10%) VAC, 50-60 (±3) Hz
Power Consumption 30 Watts maximum / 102 BTU/hr maximum
Switch architecture Store-and-forward
Address Table 6K entries, auto learning/ageing
Shared data Buffer 4 Mbit embedded memory for packet buffers
Flow Control Back pressure for half duplex, IEEE 802.3x forfull-duplex
Packet Control Runt & CRC filtering, Broadcast storm control
Switching Fabric 8.8Gbps
PoE power feeding 48VDC
PoE power consumption 260 Watts max. / 800 BTU
Switch Management
Port Configuration Port disable/enable. Auto-negotiation disable/enable. 10/100Mbps full and half
duplex mode selection. Flow control disable/enable
PoE power supply enable/disable, power feeding priority
Port Status Display each port’s disable/enable status, each port’s link status, and speed
duplex mode. Flow control status
PoE power consumption, power injection status
Trunk 7-trunk groups with up to 4-port per trunk
VLAN 26 Port-based VLAN groups
Port Mirroring 1 Mirroring port to monitor several mirrored ports. The monitor modes are
Disable, RX, TX, TX& RX
