2.1.3. HOT AIR OUTLETS
All the hot air outlets are delivered in two packages:
1 – Package containing glass
2 – rest of the material
2.1.3.1.
FLIP
1.
Complete Flip hot air outlet (1 piece)
2.
Aluminium hot air outlet support (1 piece)
3.
Aluminium hot air outlet frame (1 piece)
4.
Lamp holder (2 pieces)
5.
Halogen lamp (2 pieces)
6.
Black plastic tray (1 piece)
N.B.: pieces 2-3-4 are already assembled
2.1.3.2.
FLOAT
1. Complete Float hot air outlet (1 piece)
2. Aluminium hot air outlet support (1 piece)
3. Aluminium hot air outlet frame (1 piece)
4. Lamp holder (2 pieces)
5. Halogen lamp (2 pieces)
6. Black plastic tray (1 piece)
N.B.: pieces 2-3-4 are already assembled
